For the internal, strip-form sealing of construction joints and crack-control joints for cast-in-place concrete or precast wall elements
Features
AquaproofX® 1 is coated on one side with a reactive polymer coat that forms a permanent, highly adhesive, water-impermeable bond to the surrounding concrete. AquaproofX® 1 thus offers extremely high waterproofing security as a result. AquaproofX® 1 is resistant to organic wastewater. Connecting to expansion joint waterbars is possible without any problems with the aid of a special connector. Special order dimensions can also be supplied.
Uses
AquaproofX® 1 is suitable for all typical construction and crack-control joints: floor slab/ floor slab, floor slab /wall, wall/wall, wall/ceiling, ceiling/ ceiling. Installation is carried out with the coated side towards the water. With regard to construction joints, AquaproofX® 1 is mounted to the upper rebars. An embedment depth of 35 mm is perfectly adequate. Matching accessories simply the installation. In a precast wall element, the strip is installed along the crackcontrol joint (vertically aligned) using pre-mounted fastening clips arranged on the water-bearing side. In the area of a crack-control joint in cast-in-place concrete, special fixing brackets not only ensure the strip’s secure positioning but also purposefully weaken the cross-section thus inducing the desired crack.
| Art.-No. | Article |
|---|---|
| S03111002 | AquaproofX® 1 10 (2 m) PU 30 m |
| S03111006 | AquaproofX® 1 10 roll (6 m) PU 6 m |
| S03111402 | AquaproofX® 1 (2 m) PU 30 m 30 bundles per pallet = 900 m |
| S03111406 | AquaproofX® 1 roll (6 m) PU 6 m 84 rolls per pallet = 504 m |
| S03111410 | AquaproofX® 1 with integrated base (2 m) PU 30 m 30 bundles per pallet = 900 m |
| S03121406 | AquaproofX® 1 Set roll (6 m) PU 6 m 84 Sets per pallet = 504 m |
| S03510002 | Push bracket PU 15 Stk. |
| S03510155 | Omega fixing clip 155 mm height PU 100 Stk. |
| S03530001 | Expansion joint connector |
| S03540030 | Metal waterstop fixing bracket PU 40 Stk. |
