This system combines the positive features of a round injection hose with a full-contact, flat-lying system.
Features
WaterproofX® 100 offers a number of benefits due to its sophisticated design: its patented foam core and honeycombed cross-section ensure that the injection hose has a stable lie and provides the best possible wall-to-volume ratio. Multiple injections are possible and there are no limits to the choice of injection material (PUR foam, PUR resin, epoxy resin, polymer gel matrix/ cement). Excess lengths can be supplied without a problem (tested to 30 m).
Uses
Installation takes place on dry, level surfaces. The contact area must be free of loose particles. WaterproofX® 100 is laid flat on the first concrete section, ideally in the middle of the wall. Perfectly fitting clamps or a fixing mesh ensure it is fixed in place easily and securely. In joining areas the hoses are laid in parallel for about 15 cm (3-5 cm apart).
Accessories
- Clamps
- Fixing mesh
- Hose connectors
- Varioclix connectors
The WPX 100 all-round package ensures that all accessories required for installation are to hand on the building site.
| Art.-No. | Article |
|---|---|
| S04210120 | WaterproofX® 100 L = 120 m 3.360 m per pallet |
| S04220001 | WPX100 Set 40 m |
| S04220002 | WPX100 Set EW 40 m |
| S04220003 | WPX100 Set Plus 40 m |
| S04220004 | WPX100 Set Light 40 m |
| S04700000 | Varioclix |
| S04700005 | Varioclix with metal strip (pad black) |
| S04700005 | Varioclix with metal strip (pad grey) |
| S04810050 | PVC-hose blue L = 50 m |
| S04820050 | PVC-hose white L = 50 m |
| S04830050 | PVC-hose green L = 50 m |
| S04840050 | PVC-hose red L = 50 m |
| S04900001 | Hose connector PU 100 pcs. |
| S04900002 | Plug PU 100 pcs. |
| S04900004 | Hose clamp PU 100 pcs. |
| S04900005 | Stecki fixing clip PU 100 pcs. |
| S04900006 | Drive-in-anchor 5 x 30 mm PU 100 pcs. |
| S04910013 | an.kox clamp 13 mm PU100 pcs. |
| S04925100 | Fixing mesh X1 L = 100 cm |
| S04930012 | Mounting clip X1 for expansion joint L = 100 cm |
| S04958000 | Injection nipple M8 PU 100 pcs.. |
| S04958055 | Injection nipple M8 / 55 mm PU 100 pcs. |
